Multipurpose Municipal Waste Shredders
Paper based shredded waste can be sold | @Rs.8-12/- kg. |
Pet Bottle shredded waste can be sold | @Rs.15-30/-Kg. |
Aluminium cans shredded waste can be sold | @Rs.15-30/- kg. |
Compost manure can be sold | @Rs.7-10/-Kg. |
Polyethylen-erephthatal is fully recyclable and can be reused to make products like fibres for carpets, fibrefill, apparels & geolextiles. Can be burned for energy recovery. Can be recycled for land filling Can be recycled for making plastic granules, pellets, plastic flakes or powder. Can be recycled for plastic Tar Road
Recycling Aluminium Cans can prevent 5% of total Bauxite ore mining in the world thus saving raw material.Produces 95% reduced greenhouse gas emissions than making new cans thus saving energy.
Paper Cups, Tetra Packs, Paper Bags, Paper Board Boxes, Corrugated Card Board Cartoons, Office Paper & Junk Mail, Newspaper, Magazines & Catalogues Recycle & Re use to Make Paper Pulp & Paper
Dry Garden Waste
Reduce & Recycle the Shredded Dry Garden Waste to Compost manure.
Model | JB -300 Suitable for 100-150 kgs/hr |
JB -400 Suitable for 200-300 kgs/hr |
JB -500 Suitable for 500-1000 kgs/hr |
Technology | Twin Shaft, low speed, high torque shredder cum disentregrator. | ||
Other Features | Ultra Quiet, Sure shot grip of material to be shredded and ensures no frequent cutter wearouts. low power consumption. | ||
Shred chamber (mm) |
310-x310 |
410x410 |
410x410 |
Shred size (mm) |
6-24x50-100 |
12x50-180 |
12x50-100 |
Shred Capacity (kg/Hr) |
100-150 |
200-300 |
1/2-1 tonne per hour |
Voltage |
415V |
415V |
415V |
Power |
2.2Kw |
3.75 KW |
7.5HP |
Hopper volume (Litres) |
50L |
120L |
120L |
Waste Volume (Litres) |
180L |
335L |
335L |
Weight (kgs) |
260 Kgs |
360 Kgs |
400Kgs |
Machine Dimensions (mm) HxWxD |
1750x700x700 |
2060x800x1000 |
2060x800x1000 |
Overload Protection |
Yes |
Yes |
Yes |
Overheat Protection |
Yes |
Yes |
Yes |
Auto Reverse |
Yes |
Yes |
Yes |
Emergency stop for operator safety |
Yes |
Yes |
Yes |
Motor Start / Off |
Online starter |
online starter |
online starter |
Working cycle if operated in ventilated ambience and at 60% rated capacity |
Continuous |
Continuous |
Continuous |
Applications |
|
|
|
Paper, Documents and junk mail |
Yes |
Yes |
Yes |
Paper Bags & Tetrapacks |
Yes |
Yes |
Yes |
Paper Boards & Cartons |
Yes |
Yes |
Yes |
Pet Bottles and Plastic Waste |
Yes upto 50 mm dia/wide |
Yes upto 100 mm dia or wide |
Yes upto 100 mm dia or wide |
Aluminum Cans |
Yes |
Yes |
Yes |
Garden Waste |
Yes-with regulated feeding |
Yes-with regulated feeding |
Yes-with regulated feeding |
